"A DIY electric longboard is a rolling engineering project that you also commute on.
"KaiRenner26th of April 2026
DIY Electric Longboard Build
Build a custom electric longboard from a deck, trucks, dual hub motors or belt drives, an ESC, a lithium battery pack, and a handheld remote. Budget builds start around $300.
$400
25kph
Choose the Deck and Trucks
A 38 to 42 inch drop-through deck gives a stable, low ride height. Use 218mm trucks for stability at speed. Caliber or Paris trucks work well with most motor mounts and pulleys.
Build the Drivetrain
Hub motors are the simplest option: no belt, no pulley, motors fit inside the wheels. Belt drive gives more torque and easier wheel swaps. Choose based on your terrain and mechanical confidence.
Wire the Electronics
Mount the ESC inside a 3D printed or aluminum enclosure on the deck underside. Wire the battery to the ESC with an antispark connector. Pair the remote receiver to the ESC before final assembly.
Build Checklist
Choose deck, trucks, and motor type before ordering anything
Measure truck axle width to confirm motor hub or pulley fit
Order ESC and remote as a matched set from one supplier
Build or buy battery pack at correct voltage for your ESC
Mount ESC and battery in waterproof enclosures
Wire battery to ESC with antispark XT90 connector
Calibrate ESC to remote throttle curve before riding
Test braking at low speed before a full-speed run
VESC-based speed controllers are the most configurable option and have a strong open-source community. The VESC Tool software allows fine-tuning of motor detection, braking strength, and speed limits.
